Virtual Lab: The Inner Workings of CD/DVD Drives
University of Virginia
© 2003-Present, John C. Bean
Here is the assembly of motor and gears that drives the CD/DVD tray in and out of the drive.

Using the blue cam, the same assembly will be used to lift the rotation motor up to the disk.
