Virtual Lab: Resistors and Capacitors at High Voltage
University of Virginia
© 2003-Present, John C. Bean
In this simulation a battery will be used to charge a capacitor. The capacitor will then be used to operate a light bulb until the capacitor is discharged. The battery has a larger voltage than a single cell and will charge the capacitor to a correspondingly higher voltage. The capacitor is used to temporarily store some energy from the cell.

To start this tour, click the "Next Scene" button at the bottom of this page.

To navigate further, use the buttons at the bottom of the page. (You can also move between scenes by using your keyboard’s arrows, and then play movies by clicking enter/return).

At any point, you can jump ahead by clicking an icon above the picture. To see related webpages on this website, click the "Related Pages" button above.
